HPE Aruba CX Integration
| Version | 0.1.0 beta:[] (View all) |
| Compatible Kibana version(s) | 8.15.0 or higher 9.0.0 or higher |
| Supported Serverless project types What's this? |
Security Observability |
| Subscription level What's this? |
Basic |
| Level of support What's this? |
Elastic |
The HPE Aruba CX integration allows you to monitor the HPE Aruba Networking CX Switch. The switch series is modern, flexible, and intelligent stackable switch series ideally for enterprise network access, aggregation, core, and data center top of rack (ToR) deployments.
Use the HPE Aruba integration and follow the setup steps listed below to forward the CX Switch logging to a deployed standalone or managed Beat at a specific port listening for TCP or UDP data. Then visualize that data in Kibana, create alerts to notify you if something goes wrong, and reference log when troubleshooting data/error issue encountered in the field.
This package follows the AOS-CX 10.15 Event Log Message Reference Guide and has been tested from sample logs captured from the HPE Aruba Networking CX Switches: 6000, 6300 and 8360 on the 10.15 version of the specification. As new appliances and OSes are released, they are expected to be compatible with the integration but Elastic does not guarantee compatibility with new/old version of the product line. The integration ONLY supports logs in ENGLISH, internationalization of logs to other languages are NOT supported.
The HPE Aruba CX integration collects events into data stream: log
Elasticsearch for storing and searching your data and Kibana for visualizing and managing it. We recommend using our hosted Elasticsearch Service on Elastic Cloud, or self-manage the Elastic Stack on your own hardware.
For step-by-step instructions on how to set up an integration, see the Getting started guide.
Below are the fields from the different event types and their mapping into ECS supported fields or customer Aruba fields
Note
To Be Removed
Field types are defined within fields.yml
Note: Descriptions have not been filled out
| Doc Fields | Schema Mapping |
|---|---|
<aaa_config_type> |
aruba.aaa.config_event |
<aaa_config_event> |
aruba.aaa.config_type |
<key_length> |
aruba.len |
<max_key_length> |
aruba.limit.threshold |
<tacacs_action> |
aruba.aaa.radius_action |
<radius_event> |
aruba.aaa.radius_event |
<server_address> |
server.address |
<server_authport> |
aruba.port |
<status> |
aruba.status |
<server_vrfid> |
aruba.vrf.id |
<radius_type> |
event.type |
<tacacs_action> |
aruba.aaa.tacacs_action |
<tacacs_event> |
aruba.aaa.tacacs_event |
<server_address> |
server.address |
<server_authport> |
aruba.port |
<server_vrfid> |
aruba.vrf.id |
<tacacs_type> |
aruba.aaa.tacacs_type |
| Doc Fields | Schema Mapping |
|---|---|
<ip_address> |
client.ip |
<user_name> |
user.name |
| Doc Fields | Schema Mapping |
|---|---|
<log> |
message |
<type> |
aruba.acl.type |
<ace_string> |
aruba.acl.ace_string |
<application> |
aruba.acl.application |
<direction> |
aruba.acl.direction |
<hit_delta> |
aruba.acl.hit_delta |
<interface_name> |
aruba.interface.name |
<name> |
aruba.acl.name |
| Doc Fields | Schema Mapping |
|---|---|
<id> |
aruba.instance.id |
<length> |
aruba.len |
<log_and_trap> |
aruba.alarm.log_and_trap |
<name> |
aruba.alarm.name |
<relay> |
aruba.alarm.relay |
<trigger> |
aruba.alarm.trigger |
<type> |
aruba.alarm.type |
| Doc Fields | Schema Mapping |
|---|---|
<log> |
aruba.arc.log |
<node_id> |
aruba.instance.id |
<status> |
aruba.status |
| Doc Fields | Schema Mapping |
|---|---|
<port_name> |
aruba.port |
<status> |
aruba.status |
<vlan_id> |
network.vlan.id |
| Doc Fields | Schema Mapping |
|---|---|
<mac> |
client.mac |
<prefix_list> |
aruba.asic.prefix_list |
<route_prefix> |
aruba.asic.route_prefix |
| Doc Fields | Schema Mapping |
|---|---|
<addr> |
aruba.bfd.invalid_ip |
<applied_interval> |
aruba.bfd.applied_interval |
<dest_ip> |
destination.ip |
<direction> |
network.direction |
<from> |
aruba.bfd.from |
<intf> |
aruba.interface.id |
<ip_version> |
aruba.bfd.ip_version |
<local_diag> |
aruba.bfd.local_diag |
<local_state> |
aruba.bfd.local_state |
<op_mode> |
aruba.bfd.op_mode |
<port_name> |
aruba.port |
<remote_addr> |
client.address |
<remote_diag> |
aruba.bfd.remote_diag |
<remote_state> |
aruba.bfd.remote_state |
<requested_interval> |
aruba.bfd.requested_interval |
<session_id> |
aruba.session.id |
<src_port> |
aruba.port |
<vrf> |
aruba.vrf.id |
<vrf> |
aruba.vrf.name |
| Doc Fields | Schema Mapping |
|---|---|
<as_number> |
aruba.bgp.as_number |
<id> |
aruba.bgp.id |
<error-code> |
error.code |
<error-subcode> |
aruba.bgp.error_subcode |
<local_as> |
client.as.number |
<pg_name> |
aruba.bgp.pg_name |
<peer-grp> |
aruba.bgp.peer_grp |
<remote-addr> |
destination.address |
<remote_as> |
destination.as.number |
<src_ipaddr> |
source.ip |
<threshold_limit> |
aruba.limit.threshold |
<vrf-name> |
aruba.vrf.name |
| Doc Fields | Schema Mapping |
|---|---|
<if_index> |
aruba.interface.id |
<if_name> |
aruba.interface.name |
<ip_address> |
client.ip |
<reason> |
event.reason |
<status> |
aruba.status |
<vrf_name> |
aruba.vrf.name |
| Doc Fields | Schema Mapping |
|---|---|
<connected_disconnected> |
event.action |
<enabled_disabled> |
event.action |
<inserted_removed> |
event.action |
<mac> |
client.mac |
| Doc Fields | Schema Mapping |
|---|---|
<interface> |
aruba.interface.name |
<mac> |
source.mac |
| Doc Fields | Schema Mapping |
|---|---|
<activate_address> |
aruba.rest.activate_address |
<central_location> |
aruba.rest.central_location |
<central_source> |
aruba.rest.central_source |
<cert_length> |
aruba.len |
<vrf> |
aruba.vrf.id |
| Doc Fields | Schema Mapping |
|---|---|
<arp_end_ts> |
aruba.insight.arp_end_ts |
<assigned-role> |
aruba.role |
<assigned-role-type> |
aruba.insight.role_type |
<auth-latency> |
aruba.insight.auth_latency |
<auth-status> |
aruba.status |
<auth-type> |
aruba.insight.auth_type |
<client-number> |
aruba.limit.threshold |
<dot1x-auth-failure-reason> |
aruba.insight.dot1x_auth_failure_reason |
<dhcpv4-client> |
aruba.insight.dhcp_client |
<dhcpv4-failure-reason> |
event.reason |
<dhcpv4-latency> |
aruba.insight.dhcp_latency |
<dhcpv4-server> |
aruba.insight.dhcp_server |
<dhcpv4-status> |
aruba.status |
<dhcpv6-client> |
aruba.insight.dhcp_client |
<dhcpv6-failure-reason> |
event.reason |
<dhcpv6-latency> |
aruba.insight.dhcp_latency |
<dhcpv6-server> |
aruba.insight.dhcp_server |
<dhcpv6-status> |
aruba.status |
<dns_end_ts> |
aruba.insight.dns_end_ts |
<dns_failure_reason> |
event.reason |
<dns-failure-reason> |
event.reason |
<dns-latency> |
aruba.insight.dns_latency |
<dns_server_ip> |
server.ip |
<dns-server> |
aruba.insight.dns_server |
<dns_status> |
aruba.status |
<dns-status> |
aruba.status |
<failed_vlans> |
aruba.insight.failed_vlans |
<failure_phase_id> |
aruba.insight.failure_phase_id |
<failure_reason> |
event.reason |
<l2_end_ts> |
aruba.insight.l2_end_ts |
<l2_failure_reason> |
aruba.insight.l2_failure_reason |
<l2_ob_state> |
aruba.insight.l2_ob_state |
<l3_end_ts> |
aruba.insight.l3_end_ts |
<l3_failure_reason> |
aruba.insight.l3_failure_reason |
<l3_ob_state> |
aruba.insight.l3_ob_state |
<mac> |
client.mac |
<mac-auth-failure-reason> |
aruba.insight.mac_auth_failure_reason |
<port> |
aruba.port |
<ob_start_ts> |
aruba.insight.ob_start_ts |
<onboarding_status> |
aruba.status |
<radius-server> |
aruba.insight.radius_server |
<successfulvlan> |
aruba.insight.successfulvlan |
<vlans> |
network.vlan.id |
| Doc Fields | Schema Mapping |
|---|---|
<cert_name> |
aruba.cm.cert_name |
<days> |
aruba.cm.days |
<error> |
event.reason |
<est_name> |
aruba.cm.est_name |
<profile_name> |
aruba.cm.profile_name |
<status> |
aruba.status |
| Doc Fields | Schema Mapping |
|---|---|
<error> |
event.reason |
<from> |
aruba.config.from |
<info> |
event.action |
<to> |
aruba.config.to |
<type> |
aruba.config.type |
<value> |
aruba.config.value |
| Doc Fields | Schema Mapping |
|---|---|
<name> |
aruba.config.name |
<reason> |
event.reason |
| Doc Fields | Schema Mapping |
|---|---|
<id> |
aruba.instance.id |
<interface> |
aruba.interface.id |
| Doc Fields | Schema Mapping |
|---|---|
<ip_address> |
client.ip |
<mgmt_intf> |
aruba.interface.id |
<user_name> |
user.name |
| Doc Fields | Schema Mapping |
|---|---|
<name> |
container.name |
<params> |
aruba.container.params |
| Doc Field | Schema Mapping |
|---|---|
<class> |
aruba.copp.class |
<slot> |
aruba.slot |
| Doc Field | Schema Mapping |
|---|---|
<action> |
event.action |
<filter_description> |
aruba.cpu_rx.filter_description |
<unit> |
aruba.instance.id |
| Doc Field | Schema Mapping |
|---|---|
<key-id> |
user.id |
<user> |
user.name |
| Doc Field | Schema Mapping |
|---|
| Doc Field | Schema Mapping |
|---|---|
<client_limit> |
aruba.limit.threshold |
<interface> |
aruba.interface.id |
| Doc Field | Schema Mapping |
|---|
| Doc Field | Schema Mapping |
|---|---|
<client_id> |
user.id |
<config> |
aruba.dhcp.config |
<expiry_time> |
event.end |
<host> |
host.name |
<ip> |
host.ip |
<mac> |
host.mac |
<vfr> |
aruba.vrf.id |
<vfr_name> |
aruba.vrf.name |
| Doc Field | Schema Mapping |
|---|---|
<bindings_imported> |
client.dhcp.bindings_imported |
<client_mac> |
client.mac |
<existing_port> |
server.port |
<file_name> |
file.name |
<file_path> |
file.path |
<gateway_ip> |
aruba.dhcp.gateway_ip |
<ip_address> |
client.ip |
<lease> |
aruba.dhcp.lease |
<lease_ip_address> |
client.ip |
<mac> |
client.mac |
<message_type> |
aruba.dhcp.message_type |
<nameserver_ip> |
client.mac |
<new_port> |
aruba.dhcp.new_port |
<port> |
aruba.port |
<server_ip> |
server.ip |
<server_ip_address> |
server.ip |
<source_mac> |
client.mac |
<vid> |
network.vlan.id |
<volume_name> |
aruba.volume_name |
| Doc Field | Schema Mapping |
|---|
| Doc Fields | Schema Mapping |
|---|---|
<bindings_imported> |
client.dhcp.bindings_imported |
<existing_port> |
aruba.port |
<file_name> |
file.name |
<file_path> |
file.path |
<ip> |
client.ip |
<ipv6_address> |
client.ip, server.ip |
<lease> |
aruba.dhcp.lease |
<mac> |
client.mac |
<message_type> |
aruba.dhcp.message_type |
<nameserver_ip> |
client.mac |
<new_port> |
aruba.dhcp.new_port |
<port> |
aruba.port |
<vid> |
network.vlan.id |
<volume_name> |
aruba.dhcp.volume_name |
| Doc Fields | Schema Mapping |
|---|---|
<intf_name> |
aruba.interface.name |
| Doc Fields | Schema Mapping |
|---|---|
<active_coordinates> |
aruba.distributed.active_coordinates |
<configured_coordinates> |
aruba.distributed.configured_coordinates |
<reason> |
event.reason |
| Docs Field | Schema Mapping |
|---|---|
<type> |
aruba.dns.type |
<vrf_name> |
aruba.vrf.name |
| Docs Field | Schema Mapping |
|---|---|
<ifname> |
aruba.interface.name |
<policy> |
aruba.dot1x.policy |
<port> |
aruba.port |
| Docs Field | Schema Mapping |
|---|---|
<desc> |
aruba.error.description |
<error> |
error.code |
<url> |
aruba.port |
| Docs Field | Schema Mapping |
|---|---|
<linecard_name> |
aruba.dpse.linecard_name |
<operation_name> |
aruba.dpse.operation_name |
<plugin_name> |
aruba.dpse.plugin_name |
| Field | Schema Mapping |
|---|---|
<egressid> |
aruba.ecmp.egressid |
<err> |
aruba.ecmp.err |
<route> |
aruba.ecmp.route |
| Field | Description | Type | Common |
|---|---|---|---|
<ccvlan> |
network.vlan.id | ||
<dataVlan> |
network.vlan.id | ||
<ifID> |
aruba.interface.id | ||
<instanceID> |
aruba.instance.id | ||
<interfaceName> |
aruba.interface.name | ||
<node> |
client.mac | ||
<portName> |
aruba.port | ||
<reason> |
event.reason | ||
<ringID> |
aruba.erps.ring_id | ||
<state> |
aruba.status | ||
<vlandID> |
network.vlan.id |
| Doc Field | Schema Mapping |
|---|---|
<action> |
event.action |
<bundle_name> |
package.name |
<esi> |
aruba.evpn.esi |
<eth_tag> |
aruba.evpn.eth_tag |
<evi> |
network.vlan.id |
<ip_addr> |
client.ip |
<mac_addr> |
client.mac |
<rd> |
aruba.evpn.rd |
<rt> |
aruba.evpn.rt |
<rtt> |
aruba.evpn.rtt |
<vni> |
aruba.evpn.vni |
<vrf> |
aruba.vrf.id |
<vtep_ip> |
aruba.evpn.vtep_ip |
| Doc Field | Schema Mapping |
|---|---|
<name> |
aruba.storage.name |
<status> |
aruba.status |
| Doc Field | Schema Mapping |
|---|---|
<count> |
aruba.fan.count |
<subsystem> |
aruba.subsystem |
<speedval> |
aruba.fan.speedval |
<value> |
aruba.fan.value |
<FT_Num> |
aruba.fan.ft_name |
<FT_Name> |
aruba.fan.ft_name |
<FMod_Num> |
aruba.fan.fmod_num |
<num_of_failure> |
aruba.error.count |
<failure_type> |
error.type |
<compare_mode> |
aruba.fan.compare_mode |
<num_of_failure_limit> |
aruba.limit.threshold |
<seconds> |
aruba.time.seconds |
<reason> |
event.reason |
<function> |
aruba.fan.function |
<tray_index> |
aruba.fan.tray_idx |
<fan_index> |
aruba.fan.index |
<FanName> |
aruba.fan.name |
<FanStatus> |
aruba.status |
<FanModuleIdx> |
aruba.fan.module_idx |
<FanTrayIdx> |
aruba.fan.tray_idx |
<OldStatus> |
aruba.fan.old_status |
<NewStatus> |
aruba.status |
<FanCount> |
aruba.fan.count |
<FanMinimum> |
aruba.fan.minimum |
<ZoneIdx> |
aruba.fan.zone_idx |
<FanSpdIdxStatus> |
aruba.status |
<Status> |
aruba.status |
<FT_Dir> |
aruba.fan.ft_dir |
<FT_air_curr> |
aruba.fan.ft_air_curr |
<FT_air_req> |
aruba.fan.ft_air_req |
<En_Dis> |
aruba.status |
| Doc Fields | Schema Mapping |
|---|---|
<fault> |
aruba.fault.type |
<interface> |
aruba.interface.name |
<mac> |
client.mac |
<sa_diff_count> |
aruba.fault.sa_diff_count |
<da_diff_count> |
aruba.fault.da_diff_count |
| Doc Fields | Schema Mapping |
|---|---|
<connection_state> |
aruba.state |
<device_parameter> |
aruba.feature_pack.device_parameter |
<device_serial> |
aruba.feature_pack.device_serial |
<expiry_date> |
aruba.feature_pack.expiry_date |
<feature_name> |
aruba.feature_pack.feature_name |
<feature_pack_mode> |
aruba.feature_pack.mode |
<feature_pack_name> |
aruba.feature_pack.name |
<feature_pack_type> |
aruba.feature_pack.type |
<parameter_type> |
aruba.feature_pack.parameter_type |
<parameter_type> |
aruba.feature_pack.parameter_type_mismatch |
<subscription_parameter> |
aruba.feature_pack.subscription_parameter |
| Doc Fields | Schema Mapping |
|---|---|
<after> |
aruba.firmware.after |
<before> |
aruba.firmware.before |
<dnld_type> |
aruba.firmware.dnld_type |
<host> |
source.address |
<hotpatch_name> |
aruba.firmware.hotpatch_name |
<image_profile> |
aruba.firmware.image_profile |
<user> |
user.name |
| Doc Fields | Schema Mapping |
|---|---|
<classA_ded> |
aruba.fqtss.classA_ded |
<classA_max> |
aruba.fqtss.classA_max |
<classB_ded> |
aruba.fqtss.classB_ded |
<classB_max> |
aruba.fqtss.classB_max |
<dedicate_mem_status> |
aruba.fqtss.dedicate_mem_status |
<individual_status_of_all> |
aruba.status |
<per_port_consolidate_status> |
aruba.fqtss.per_port_consolidate_status |
<per_port_per_stream_consolidate_status> |
aruba.fqtss.per_port_per_stream_consolidate_status |
<per_port_status> |
aruba.fqtss.per_port_status |
<per_stream_consolidate_status> |
aruba.fqtss.per_stream_consolidate_status |
<per_stream_status> |
aruba.fqtss.per_stream_status |
<port_name> |
aruba.port |
<req_type> |
aruba.fqtss.request_type |
<request_type> |
aruba.fqtss.request_type |
<stream_hw_status> |
aruba.fqtss.stream_hw_status |
<stream_meter_id> |
aruba.fqtss.stream_meter_id |
<streamid> |
aruba.instance.id |
| Doc Fields | Schema Mapping |
|---|---|
<addr> |
aruba.hardware.addr |
<bus> |
aruba.hardware.bus |
<cap> |
aruba.hardware.cap |
<cecount> |
aruba.hardware.cecount |
<channel> |
aruba.hardware.channel |
<cpus> |
aruba.hardware.cpus |
<device> |
aruba.hardware.device |
<error_code> |
error.code |
<function> |
aruba.hardware.function |
<impact_statement> |
aruba.hardware.impact_statement |
<level> |
aruba.hardware.level |
<location> |
aruba.hardware.location |
<mcgstatus> |
aruba.hardware.mcgstatus |
<misc> |
aruba.hardware.misc |
<offlined> |
aruba.hardware.offlined |
<origin> |
aruba.hardware.origin |
<page> |
aruba.hardware.page |
<seg> |
aruba.hardware.seg |
<slot> |
aruba.slot |
<socket> |
aruba.hardware.socket |
<status> |
aruba.status |
<test_name> |
aruba.hardware.test_name |
<threshold> |
aruba.limit.threshold |
<type> |
aruba.hardware.type |
| Doc Fields | Schema Mapping |
|---|---|
<ip> |
server.ip |
<mac> |
server.mac |
<mac> |
destination.mac |
<port> |
aruba.port |
<vni> |
network.vlan.id |
| Doc Fields | Schema Mapping |
|---|---|
<patch_name> |
package.name |
<ss_type_ss_name> |
aruba.hotpatch.ss |
<status> |
aruba.status |
| Doc Fields | Schema Mapping |
|---|---|
<mode> |
aruba.server.mode |
<sessions> |
aruba.server.sessions |
<status> |
aruba.status |
<timeout> |
aruba.timeout |
<user> |
server.user.name |
<vrf> |
aruba.vrf.id |
| Doc Fields | Schema Mapping |
|---|---|
<name> |
aruba.injected_view.name |
| Doc Fields | Schema Mapping |
|---|---|
<devicespec> |
aruba.system.devicespec |
<file> |
file.name |
<fromver> |
service.version |
<line> |
aruba.system.line |
<modspec> |
aruba.system.modspec |
<numdevs> |
aruba.system.numdevs |
<pass> |
event.action |
<time> |
aruba.system.time |
<tover> |
service.target.version |
| Doc Fields | Schema Mapping |
|---|---|
<count> |
aruba.count |
<interface> |
aruba.interface.id |
<port_speed> |
aruba.interface.port_speed |
<state> |
aruba.state |
| Doc Fields | Schema Mapping |
|---|---|
<error> |
event.reason |
<module_num> |
aruba.slot |
<name> |
aruba.storage.name |
<usage> |
aruba.storage.usage |
| Doc Fields | Schema Mapping |
|---|
| Doc Fields | Schema Mapping |
|---|---|
<node_id> |
aruba.instance.id |
<status> |
aruba.status |
| Docs Field | Schema Mapping |
|---|---|
<interface> |
aruba.interface.id |
<max_supported_limit> |
aruba.limit.threshold |
| Doc Fields | Schema Mapping |
|---|---|
<dst_ip> |
destination.ip |
<ip_mtu> |
aruba.mtu |
<tunnel_name> |
aruba.tunnel.name |
<src_ip> |
source.ip |
<ttl> |
aruba.tunnel.ttl |
<type> |
aruba.tunnel.type |
<vrf> |
aruba.vrf.id |
| Doc Fields | Schema Mapping |
|---|---|
<interface> |
aruba.interface.id |
<name> |
aruba.ip_sla.name |
<operation> |
event.action |
<reason> |
event.reason |
<state> |
aruba.state |
| Doc Fields | Schema Mapping |
|---|---|
<tunnel_id> |
aruba.instance.id |
| Doc Fields | Schema Mapping |
|---|---|
<intf> |
aruba.interface.id |
<ipv6_addr> |
server.ip |
<prefix> |
aruba.prefix |
<prefixlen> |
aruba.len |
<route> |
aruba.ip_ra.route |
| Docs Field | Schema Mapping |
|---|---|
<interface> |
aruba.interface.id |
| Docs Field | Schema Mapping |
|---|---|
<action> |
event.action |
<active_bank> |
aruba.issu.active_bank |
<condition> |
aruba.issu.condition |
<error_type> |
error.type |
<feature> |
aruba.issu.feature |
<location> |
aruba.issu.location |
<new_software_version> |
aruba.issu.new_software_version |
<not_ready_reason> |
event.reason |
<operation> |
aruba.issu.operation |
<previous_software_version> |
aruba.issu.previous_software_version |
<reason_message> |
event.reason |
<version> |
host.os.version |
<wait_time> |
aruba.issu.wait_time |
| Docs Field | Schema Mapping |
|---|---|
<details> |
aruba.scheduler.details |
<job_name> |
aruba.scheduler.job_name |
<name> |
aruba.scheduler.name |
<schedule_name> |
aruba.scheduler.name |
<start_datetime> |
aruba.scheduler.datetime |
<trigger_count> |
aruba.count |
| Docs Field | Schema Mapping |
|---|---|
<encaps_allocated> |
aruba.l3.encaps_allocated |
<encaps_free> |
aruba.l3.encaps_free |
| Docs Field | Schema Mapping |
|---|---|
<nexthop> |
aruba.l3.nexthop |
<object> |
aruba.l3.object |
<percent> |
aruba.l3.percent |
<prefix> |
aruba.prefix |
<resource> |
aruba.l3.resource |
<vtep> |
aruba.l3.vtep |
| Docs Field | Schema Mapping |
|---|---|
<actor_state> |
aruba.lacp.actor_state |
<fallback> |
aruba.lacp.fallback |
<fsm_state> |
aruba.lacp.fsm_state |
<intf_id> |
aruba.interface.id |
<intf_id> |
aruba.interface.prev_id |
<intf_name> |
aruba.interface.name |
<lacp_fallback_mode> |
aruba.lacp.fallback_mode |
<lacp_fallback_timeout> |
aruba.timeout |
<mode> |
aruba.lacp.mode |
<lacp_rate> |
aruba.lacp.rate |
<lag_id> |
aruba.instance.id |
<lag_number> |
aruba.lacp.lag_number |
<lag_speed> |
aruba.lacp.lag_speed |
<lacp_mode> |
aruba.lacp.lacp_mode |
<partner_state> |
aruba.lacp.partner_state |
<partner_sys_id> |
aruba.lacp.partner_sys_id |
<port_speed> |
aruba.lacp.port_speed |
<system_id> |
aruba.lacp.system_id |
<system_priority> |
aruba.lacp.system_priority |
| Docs Field | Schema Mapping |
|---|---|
<error> |
event.reason |
<hw_port> |
aruba.port |
<interface> |
aruba.interface.id |
<lag_id> |
aruba.instance.id |
<mode> |
aruba.lag.mode |
<port> |
aruba.port |
<psc> |
aruba.lag.psc |
<rc> |
error.code |
<tid> |
process.thread.id |
<unit> |
aruba.unit |
<vlan> |
network.vlan.id |
| Docs Field | Schema Mapping |
|---|---|
<daemon> |
aruba.launchd.daemon |
| Docs Field | Schema Mapping |
|---|---|
<addr> |
server.address |
<addr_status> |
aruba.status |
<egress_id> |
observer.egress.interface.id |
<err> |
event.reason |
<ifname> |
aruba.interface.name |
<interface> |
aruba.interface.id |
<intf> |
aruba.interface.id |
<ip-address> |
host.ip |
<ipaddr> |
host.ip |
<lender_port_name> |
aruba.port |
<mtu> |
aruba.mtu |
<nexthop> |
aruba.l3.nexthop |
<port> |
aruba.port |
<prefix> |
aruba.prefix |
<state> |
aruba.state |
<value> |
server.ip |
<vlanid> |
network.vlan.id |
| Docs Field | Schema Mapping |
|---|---|
<count> |
aruba.count |
<subsystem> |
aruba.subsystem |
| Docs Field | Schema Mapping |
|---|---|
<chassisid> |
aruba.instance.id |
<interface> |
aruba.interface.id |
<ninterface> |
aruba.lldp.ninterface |
<npvid> |
aruba.lldp.npvid |
<pvid> |
aruba.lldp.pvid |
<hold> |
aruba.lldp.tx_hold |
<value> |
aruba.lldp.tx_delay |
<value> |
aruba.lldp.reinit_delay |
<value> |
aruba.lldp.tx_timer |
<value> |
server.ip |
| Docs Field | Schema Mapping |
|---|---|
<currvportCount> |
aruba.limit.read_value |
<portName> |
aruba.port |
<rxportName> |
aruba.loop.rx_port |
<txportName> |
aruba.loop.tx_port |
<vlan> |
network.vlan.id |
<vportLimit> |
aruba.limit.threshold |
| Docs Field | Schema Mapping |
|---|---|
<interface> |
aruba.interface.id |
<state> |
aruba.state |
| Docs Field | Schema Mapping |
|---|---|
<from-intf> |
aruba.interface.prev_id |
<intf> |
aruba.interface.id |
<mac> |
server.mac |
<to-intf> |
aruba.mac.interface.id |
<vlan> |
network.vlan.id |
| Docs Field | Schema Mapping |
|---|---|
<current> |
aruba.limit.read_value |
<mac> |
server.mac |
<max> |
aruba.limit.threshold |
<new_mode> |
aruba.mac.new_mode |
<old_mode> |
aruba.mac.old_mode |
<vlan> |
network.vlan.id |
| Docs Field | Schema Mapping |
|---|---|
<from-intf> |
aruba.interface.prev_id |
<intf> |
aruba.interface.id |
<mac> |
server.mac |
<to-intf> |
aruba.mac.interface.id |
<vlan> |
network.vlan.id |
| Docs Field | Schema Mapping |
|---|---|
<ckn> |
aruba.mac.ckn |
<feature> |
aruba.mac.feature |
<ifname> |
aruba.interface.name |
<id> |
aruba.instance.id |
<latest_an> |
aruba.mac.latest_an |
<latest_kn> |
aruba.mac.latest_kn |
<name> |
aruba.port |
<old_an> |
aruba.mac.old_an |
<old_kn> |
aruba.mac.old_kn |
<reason> |
event.reason |
<sci> |
aruba.mac.sci |
| Docs Field | Schema Mapping |
|---|---|
<mgmt_intf_config_crit> |
aruba.mgmt.config_crit |
<mgmt_intf_config_err> |
aruba.mgmt.config_err |
<mgmt_intf_config_param> |
aruba.mgmt.config_param |
| Docs Field | Schema Mapping |
|---|
| Docs Field | Schema Mapping |
|---|---|
<acl_name> |
aruba.acl.name |
<if_name> |
aruba.interface.name |
<ip_address> |
client.ip |
<l3Port> |
aruba.mgmd.l3_port |
<mgmd_type> |
aruba.mgmd.mgmd_type |
<pkt_type> |
aruba.mgmd.pkt_type |
<port> |
aruba.port |
<port_name> |
aruba.port |
<port0> |
aruba.port |
<port1> |
aruba.mgmd.port1 |
<protocol> |
aruba.mgmd.protocol |
<ring_id> |
aruba.mgmd.ring_id |
<size_value> |
aruba.len |
<state> |
aruba.state |
<status> |
aruba.status |
<sub_system> |
aruba.subsystem |
<type> |
aruba.mgmd.type |
<vlan> |
network.vlan.id |
| Docs Field | Schema Mapping |
|---|---|
<number> |
aruba.session.id |
| Docs Field | Schema Mapping |
|---|---|
<name> |
aruba.module.name |
<new_part> |
aruba.module.new_part |
<old_part> |
aruba.module.old_part |
<part_number> |
aruba.unit |
<priority> |
aruba.priority |
<reason> |
event.reason |
<type> |
aruba.module.type |
| Docs Field | Schema Mapping |
|---|---|
<local_ldp_id> |
aruba.mpls.local_ldp_id |
<peer_ldp_id> |
aruba.mpls.peer_ldp_id |
| Docs Field | Schema Mapping |
|---|---|
<grp_ip> |
aruba.msdp.grp_ip |
<if_name> |
aruba.interface.name |
<peer_ip> |
client.ip |
<port> |
aruba.port |
<rp_ip> |
aruba.msdp.rp_ip |
<src_ip> |
source.ip |
<state> |
aruba.state |
<status> |
aruba.status |
<tcp_entity> |
aruba.msdp.tcp_entity |
<vrf_name> |
aruba.vrf.name |
| Docs Field | Schema Mapping |
|---|---|
<decl_type> |
aruba.msrp.decl_type |
<name> |
aruba.port |
<port> |
aruba.port |
<reason> |
event.reason |
<status> |
aruba.status |
<streamid> |
aruba.instance.id |
| Docs Field | Schema Mapping |
|---|---|
<encap_type> |
aruba.multicast.encap_type |
<flood_group_ip> |
aruba.multicast.flood_group_ip |
<flood_group_range> |
aruba.multicast.flood_group_range |
<hw_status> |
aruba.state |
<ip_assign_method> |
aruba.multicast.ip_assign_method |
<isl_rule> |
aruba.multicast.isl_rule |
<oper_state> |
aruba.state |
<override_group_ip> |
aruba.multicast.override_group_ip |
<rep_mode> |
aruba.multicast.rep_mode |
<state> |
aruba.state |
<status> |
aruba.status |
<ulay_l2_port> |
aruba.multicast.ulay_l2_port |
<ulay_l3_port> |
aruba.multicast.ulay_l3_port |
<vni_id> |
aruba.multicast.vni_id |
| Docs Field | Schema Mapping |
|---|---|
<limit> |
aruba.limit.threshold |
<mgmd_type> |
aruba.multicast.mgmd_type |
<status> |
aruba.status |
| Docs Field | Schema Mapping |
|---|---|
<config_parameter> |
aruba.mstp.config_parameter |
<instance> |
aruba.instance.id |
<mac> |
source.mac |
<new_mac> |
source.mac |
<new_mode> |
aruba.mstp.new_mode |
<new_port> |
aruba.port |
<new_priority> |
aruba.priority |
<old_mac> |
aruba.mstp.old_mac |
<old_mode> |
aruba.mstp.old_mode |
<old_port> |
aruba.mstp.old_port |
<old_priority> |
aruba.mstp.old_priority |
<pkt_type> |
aruba.mstp.pkt_type |
<port> |
aruba.port |
<priority_mac> |
aruba.mstp.priority_mac |
<proto> |
aruba.mstp.proto |
<reconfig_parameter> |
aruba.mstp.reconfig_parameter |
<state> |
aruba.state |
<value> |
aruba.mstp.config_value |
| Docs Field | Schema Mapping |
|---|---|
<port> |
aruba.port |
<vlan> |
network.vlan.id |
<vlan_max> |
aruba.limit.threshold |
| Docs Field | Schema Mapping |
|---|---|
<name> |
aruba.nae.name |
| Docs Field | Schema Mapping |
|---|---|
<condition> |
aruba.nae.condition |
<monitorName> |
aruba.nae.monitor_name |
<name> |
aruba.nae.name |
<uri> |
url.original |
<user> |
user.name |
| Docs Field | Schema Mapping |
|---|---|
<agent> |
aruba.nae.name |
<reason> |
event.reason |
| Docs Field | Schema Mapping |
|---|---|
<action_type> |
aruba.nae.action_type |
<agent> |
aruba.nae.name |
<condition> |
aruba.nae.condition |
<description> |
aruba.nae.description |
<msg> |
message |
<name> |
aruba.nae.name |
| Docs Field | Schema Mapping |
|---|---|
<count> |
aruba.count |
<ip> |
server.ip |
<src_mac> |
source.mac |
<port> |
aruba.port |
<status> |
aruba.status |
<type> |
aruba.nd.type |
<vid> |
network.vlan.id |
<vlan> |
network.vlan.id |
| Docs Field | Schema Mapping |
|---|---|
<ip> |
client.ip |
<mac> |
client.mac |
<new_mac> |
client.mac |
<old_mac> |
aruba.ndm.old_mac |
<port> |
aruba.port |
<role> |
aruba.role |
<role1> |
aruba.ndm.old_role |
<role2> |
aruba.role |
<time> |
aruba.time.seconds |
<throttle_count> |
aruba.throttle_count |
<vrf> |
aruba.vrf.id |
| Docs Field | Schema Mapping |
|---|---|
<event> |
aruba.ntp.event |
<new> |
aruba.state |
<old> |
aruba.ntp.old |
<server> |
server.address |
<server_info> |
aruba.ntp.server_info |
<trusted_keys> |
aruba.ntp.trusted_keys |
<untrusted_keys> |
aruba.ntp.untrusted_keys |
| Docs Field | Schema Mapping |
|---|---|
<action> |
event.action |
<area> |
aruba.ospf.area |
<destination> |
destination.address |
<err> |
event.reason |
<event> |
aruba.ospf.event |
<external> |
aruba.ospf.external |
<fp_id> |
aruba.ospf.fp_id |
<group_id> |
group.id |
<input> |
aruba.ospf.input |
<inter> |
aruba.ospf.inter |
<interface> |
aruba.interface.id |
<intra> |
aruba.ospf.intra |
<new> |
aruba.ospf.router_id |
<new_state> |
aruba.state |
<next_state> |
aruba.state |
<nexthops> |
aruba.ospf.nexthops |
<old> |
aruba.ospf.old_router_id |
<old_state> |
aruba.ospf.old_state |
<ospf-interface> |
aruba.interface.id |
<process-id> |
process.pid |
<reason> |
event.reason |
<router-id> |
aruba.ospf.router_id |
<rule> |
rule.name |
<source-ip> |
source.ip |
<state> |
aruba.state / aruba.ospf.old_state |
<stats_id> |
aruba.ospf.stats_id |
<vrf> |
aruba.vrf.id |
| Docs Field | Schema Mapping |
|---|---|
<action> |
event.action |
<area> |
aruba.ospf.area |
<err> |
event.reason |
<external> |
aruba.ospf.external |
<fp_id> |
aruba.ospf.fp_id |
<group_id> |
group.id |
<input> |
aruba.ospf.input |
<inter> |
aruba.ospf.inter |
<interface> |
aruba.interface.id |
<intra> |
aruba.ospf.intra |
<link-local> |
aruba.ospf.link_local |
<new_state> |
aruba.state |
<old_state> |
aruba.ospf.old_state |
<process-id> |
process.pid |
<reason> |
event.reason |
<router-id> |
aruba.ospf.router_id |
<rule> |
rule.name |
<stats_id> |
aruba.ospf.stats_id |
<vrf> |
aruba.vrf.id |
| Docs Field | Schema Mapping |
|---|---|
<reason> |
event.reason |
<session_name> |
aruba.packet_capture.session_name |
<value> |
aruba.packet_capture.value |
| Docs Field | Schema Mapping |
|---|
| Docs Field | Schema Mapping |
|---|---|
<action_str> |
event.action |
<callerid> |
aruba.pim.callerid |
<capacity_type> |
aruba.pim.capacity_type |
<dip0> |
aruba.pim.dip0 |
<dip1> |
aruba.pim.dip1 |
<dip2> |
aruba.pim.dip2 |
<dip3> |
aruba.pim.dip3 |
<ebsr_ip> |
aruba.pim.ebsr_ip |
<err> |
aruba.error.description |
<error> |
event.reason |
<error_value> |
aruba.pim.error_value |
<event> |
aruba.pim.event |
<fd> |
aruba.pim.fd |
<flowtype> |
aruba.pim.flowtype |
<group> |
group.name |
<ifname> |
aruba.interface.name |
<InterfaceName> |
aruba.interface.name |
<ip_address> |
server.ip |
<ip_version> |
aruba.pim.ip_version |
<isl_status> |
aruba.status |
<limit> |
aruba.limit.threshold |
<mode> |
aruba.pim.mode |
<neighbor_ip> |
client.ip |
<pim_version> |
package.version |
<pkt> |
network.packets |
<pkt_type> |
aruba.pim.pkt_type |
<port> |
aruba.port |
<priority> |
aruba.priority |
<qsize> |
aruba.pim.qsize |
<reason> |
event.reason |
<sip0> |
aruba.pim.sip0 |
<sip1> |
aruba.pim.sip1 |
<sip2> |
aruba.pim.sip2 |
<sip3> |
aruba.pim.sip3 |
<source> |
source.ip |
<srcport> |
aruba.port |
<srcvid> |
network.vlan.id |
<state> |
aruba.state |
<status> |
aruba.status |
<totalvid> |
aruba.pim.totalvid |
<type> |
aruba.pim.type |
<val> |
aruba.limit.read_value |
<value> |
aruba.pim.error_value |
<vrf_name> / <vrfname> |
aruba.vrf.name |
| Docs Field | Schema Mapping |
|---|---|
<application> |
aruba.policy.application |
<policy_name> |
aruba.policy.name |
| Docs Field | Schema Mapping |
|---|---|
<address> |
client.address |
<auth-method> |
aruba.port_access.auth_method |
<error_cause> |
event.action |
<failure-reason> |
event.reason |
<feature> |
aruba.port_access.feature |
<if_name> |
aruba.interface.name |
<ip> |
url.domain |
<limit> |
aruba.limit.threshold |
<mac_address> |
client.mac |
<mac_addr> |
client.mac |
<mode> |
aruba.port_access.mode |
<monitor_name> |
aruba.port_access.monitor_name |
<new_limit> |
aruba.limit.threshold |
<new_name> |
aruba.port_access.name |
<new_mode> |
aruba.port_access.mode |
<new_limit> |
aruba.limit.threshold |
<num-cached-clients> |
aruba.port_access.num_cached_clients |
<old_mode> |
aruba.port_access.old_mode |
<old_name> |
aruba.port_access.old_name |
<policy_name> |
aruba.policy.name |
<port> |
aruba.port |
<port> |
url.port |
<port-name> |
aruba.port |
<port_name> |
aruba.port |
<proto> |
url.scheme |
<request_id> |
aruba.port_access.request_id |
<request-id> |
aruba.port_access.request_id |
<request_pkt> |
aruba.port_access.request_pkt |
<response> |
event.reason |
<server_list> |
aruba.port_access.server_list |
<role-name> |
aruba.role |
<role_name> |
aruba.role |
<vlan_id> |
network.vlan.id |
<vrf-name> |
aruba.vrf.name |
| Docs Field | Schema Mapping |
|---|---|
<client> |
aruba.pac_abp.client |
<line_card> |
aruba.pac_abp.line_card |
<operation> |
aruba.pac_abp.operation |
<pac_abp_name> |
aruba.pac_abp.name |
<result> |
aruba.pac_abp.result |
| Docs Field | Schema Mapping |
|---|---|
<action> |
event.action |
<client> |
aruba.pac_gbp.client |
<line_card> |
aruba.pac_gbp.line_card |
<pac_gbp_name> |
aruba.pac_gbp.name |
<operation> |
aruba.pac_gbp.operation |
<result> |
aruba.pac_gbp.result |
| Docs Field | Schema Mapping |
|---|---|
<cprole_error_string> |
event.reason |
<role_name> |
aruba.role |
| Docs Field | Schema Mapping |
|---|---|
<error> |
event.reason |
<interface> |
aruba.interface.id |
<ip_address> |
client.ip |
<mtu> |
aruba.mtu |
<policy> |
aruba.policy.name |
<port> |
aruba.port |
<status> |
aruba.status |
<vlan> |
network.vlan.id |
| Docs Field | Schema Mapping |
|---|---|
<if_name> |
aruba.interface.name |
<mac_addr> |
client.mac |
<port> |
aruba.port |
| Docs Field | Schema Mapping |
|---|---|
<name> |
aruba.port |
| Docs Field | Schema Mapping |
|---|---|
<alert> |
aruba.power.alert |
<failures> |
aruba.count |
<fanidx> |
aruba.power.fanidx |
<fault> |
aruba.power.fault |
<name> |
aruba.power.name |
<redund> |
aruba.power.redund |
<sensorid> |
aruba.power.sensorid |
<state> |
aruba.state |
<status> |
aruba.status |
<Support> |
aruba.power.support |
<Type> |
aruba.power.type |
<warnings> |
aruba.count |
| Docs Field | Schema Mapping |
|---|---|
<assigned_class> |
aruba.poe.assigned_class |
<assigned_class_A> |
aruba.poe.assigned_class_a |
<assigned_class_B> |
aruba.poe.assigned_class_b |
<cntrl_name> |
aruba.poe.cntrl_name |
<duration> |
aruba.poe.duration |
<fault_type> |
aruba.poe.fault_type |
<interface_name> |
aruba.interface.name |
<threshold_limit> |
aruba.limit.threshold |
<pair> |
aruba.poe.pair |
<paira_class> |
aruba.poe.paira_class |
<pairb_class> |
aruba.poe.pairb_class |
<pd_class> |
aruba.poe.pd_class |
<pd_type> |
aruba.poe.pd_type |
<power> |
aruba.power.value |
<power_available> |
aruba.power.available |
<power_drawn> |
aruba.power.value |
<req_class> |
aruba.poe.req_class |
<req_class_a> |
aruba.poe.req_class_a |
<req_class_b> |
aruba.poe.req_class_b |
<subsys_name> |
aruba.poe.subsys_name |
| Docs Field | Schema Mapping |
|---|---|
<action> |
event.action |
<clock_step> |
aruba.ptp.clock_step |
<curr_offset> |
aruba.ptp.curr_offset |
<delay_mechanism> |
aruba.ptp.delay_mechanism |
<grandsource> |
aruba.ptp.grandsource |
<high_limit> |
aruba.ptp.high_limit |
<int_name> |
aruba.interface.name |
<lag_name> |
aruba.ptp.lag_name |
<low_limit> |
aruba.ptp.low_limit |
<name> |
aruba.interface.name |
<new> |
aruba.ptp.new |
<old> |
aruba.ptp.old |
<parent> |
aruba.ptp.parent |
<port> |
aruba.port |
<priority1> |
aruba.ptp.priority1 |
<priority2> |
aruba.ptp.priority2 |
<profile> |
aruba.ptp.profile |
<quality> |
aruba.ptp.quality |
<reason> |
event.reason |
<state> |
aruba.state |
<transport> |
aruba.ptp.transport |
<type> |
aruba.ptp.type |
<value> |
aruba.ptp.value / aruba.port / source.ip |
| Docs Field | Schema Mapping |
|---|---|
<port> |
aruba.port |
<vrf> |
aruba.vrf.id |
| Docs Field | Schema Mapping |
|---|---|
<error_string> |
event.reason |
<existing_slot> |
aruba.slot |
<local_slot> |
aruba.slot |
<new_slot> |
aruba.qos.new_slot |
<port_name> |
aruba.port |
<pri> |
aruba.priority |
<queue> |
aruba.qos.queue |
<val> |
error.code |
| Docs Field | Schema Mapping |
|---|---|
<error> |
event.reason |
<error_string> |
event.reason |
<ifname> |
aruba.interface.name |
<limit> |
aruba.limit.threshold |
<warning_string> |
event.reason |
| Docs Field | Schema Mapping |
|---|
| Docs Field | Schema Mapping |
|---|---|
<Current_Virtual_Ports> |
aruba.limit.read_value |
<interface> |
aruba.interface.id |
<lvlan> |
aruba.limit.threshold |
<mac> |
client.mac |
<Maximum_Virtual_Ports> |
aruba.limit.threshold |
<new_mac> |
client.mac |
<new_mode> |
aruba.rpvst.new_mode |
<new_port> |
aruba.port |
<new_priority> |
aruba.priority |
<npvid> |
aruba.rpvst.npvid |
<old_mac> |
aruba.rpvst.old_mac |
<old_mode> |
aruba.rpvst.old_mode |
<old_port> |
aruba.rpvst.old_port |
<old_priority> |
aruba.rpvst.old_priority |
<port> |
aruba.port |
<pkt_type> |
aruba.rpvst.pkt_type |
<priority_mac> |
client.mac |
<proto> |
aruba.rpvst.proto |
<pvid> |
aruba.rpvst.pvid |
<instance> |
aruba.instance.id |
<vlan> |
network.vlan.id |
| Docs Field | Schema Mapping |
|---|---|
<tac_status> |
aruba.status |
| Docs Field | Schema Mapping |
|---|---|
<mgmt_module> |
aruba.redundant.mgmt_module |
<reason> |
event.reason |
| Docs Field | Schema Mapping |
|---|---|
<uuid_str> |
aruba.instance.id |
| Docs Field | Schema Mapping |
|---|---|
<action> |
event.action |
<added_user> |
aruba.rest.added_user |
<added_user_role> |
aruba.role |
<autztype> |
aruba.rest.autztype |
<central_location> |
aruba.rest.central_location |
<central_source> |
aruba.rest.central_source |
<command> |
aruba.rest.command |
<config_name> |
aruba.rest.config_name |
<deleted_user> |
aruba.rest.deleted_user |
<dns> |
aruba.rest.ip |
<dns_nameserver> |
aruba.rest.dns_nameserver |
<error> |
event.reason |
<from_name> |
aruba.rest.config_from_name |
<identity> |
aruba.rest.identity |
<ip_address> |
client.ip |
<match> |
aruba.rest.match |
<mgmt_intf> |
aruba.interface.id |
<mode> |
aruba.rest.mode |
<name> |
aruba.rest.name |
<resource> |
aruba.rest.resource |
<rest_operation> |
aruba.rest.operation |
<sessionid> |
aruba.session.id |
<source_ip> |
source.ip |
<subscriber> |
aruba.rest.subscriber |
<subscription> |
aruba.rest.subscription |
<to_name> |
aruba.rest.config_to_name |
<uri> |
url.original |
<url> |
url.original |
<user> |
user.name |
<vrf> |
aruba.vrf.id |
<vrf_name> |
aruba.vrf.name |
<value> |
aruba.rest.type |
| Docs Field | Schema Mapping |
|---|---|
<interface> |
aruba.interface.id |
<slot> |
aruba.slot |
<stack> |
aruba.self_test.stack |
<subsystem> |
aruba.subsystem |
<value> |
event.reason |
| Docs Field | Schema Mapping |
|---|
| Docs Field | Schema Mapping |
|---|---|
<bridge> |
aruba.sflow.bridge |
<chain> |
aruba.sflow.chain |
<desc> |
aruba.error.description |
<dgramsize> |
aruba.sflow.dgramsize |
<error> |
event.reason |
<file> |
file.name |
<hdrlen> |
aruba.len |
<ifIndex> |
aruba.interface.id |
<interface> |
aruba.interface.id |
<intvl> |
aruba.sflow.intvl |
<ip_addr> |
client.ip |
<ip_address> |
client.ip |
<mode> |
aruba.sflow.mode |
<new_rate> |
aruba.sflow.new_rate |
<old_rate> |
aruba.sflow.old_rate |
<operation> |
aruba.sflow.operation |
<port> |
aruba.port |
<port_name> |
aruba.port |
<unit> |
aruba.unit |
| Docs Field | Schema Mapping |
|---|---|
<from> |
source.address |
<status> |
aruba.status |
<to> |
destination.address |
| Docs Field | Schema Mapping |
|---|---|
<id> |
group.id |
<id> |
network.vlan.id |
<ifName> |
aruba.interface.name |
| Docs Field | Schema Mapping |
|---|---|
<truth_value> |
aruba.snmp.truth_value |
<vrf> |
aruba.vrf.id |
| Docs Field | Schema Mapping |
|---|---|
<ipaddr> |
server.ip |
<port_num> |
server.port |
<username> |
user.name |
<vrf_name> |
aruba.vrf.name |
| Docs Field | Schema Mapping |
|---|---|
<ip_address> |
client.ip |
<key_name> |
aruba.ssh.key_name |
<mgmt_intf> |
aruba.interface.id |
<new_ip> |
aruba.ssh.new_ip |
<original_ip> |
client.ip |
<username> |
user.name |
<vrf_name> |
aruba.vrf.name |
| Docs Field | Schema Mapping |
|---|---|
<boot_id> |
host.boot.id |
<boot_count_status> |
aruba.status |
<daemons> |
aruba.supportability.daemons |
<err_desc> |
aruba.error.description |
<index> |
aruba.supportability.alarm_index |
<log_type> |
aruba.supportability.log_type |
<module> |
aruba.supportability.module |
<name> |
file.name |
<oid> |
aruba.supportability.oid |
<process> |
process.name |
<reason> |
event.reason |
<remote_host> |
client.address |
<signal> |
process.exit_code |
<state> |
aruba.state |
<threshold> |
aruba.limit.threshold |
<timestamp> |
process.end |
<type> |
file.type |
<vrf> |
aruba.vrf.id |
| Docs Field | Schema Mapping |
|---|---|
<error_sbe> |
aruba.error.description |
<module> |
aruba.sys.module |
<value> |
aruba.sys.name |
| Docs Field | Schema Mapping |
|---|---|
<mem_usage> |
aruba.sysmon.mem_usage |
<module_name> |
aruba.sysmon.module_name |
<module_num> |
aruba.sysmon.module_num |
<partition_name> |
aruba.sysmon.partition_name |
<poll> |
aruba.sysmon.poll |
<unit> |
aruba.sysmon.unit |
<unit_count> |
aruba.sysmon.unit_count |
<utilization> |
aruba.sysmon.utilization |
| Docs Field | Schema Mapping |
|---|---|
<table_name> |
aruba.tcam.table_name |
| Docs Field | Schema Mapping |
|---|---|
<ip_address> |
client.ip |
<mgmt_intf> |
aruba.interface.id |
<user_name> |
user.name |
<vrf_name> |
aruba.vrf.name |
| Docs Field | Schema Mapping |
|---|---|
<name> |
aruba.temp.name |
<new> |
aruba.temp.new |
<limit_high> |
aruba.limit.threshold |
<limit_low> |
aruba.limit.threshold |
<limit_type> |
aruba.temp.limit_type |
<module> |
aruba.temp.module |
<old> |
aruba.temp.old |
<status> |
aruba.status |
<temp> |
aruba.temp.celsius |
<type> |
aruba.temp.type |
<t_high> |
aruba.temp.t_high |
<t_low> |
aruba.temp.t_low |
| Docs Field | Schema Mapping |
|---|---|
<new_time> |
aruba.time.new_time |
<newtz> |
aruba.time.new_tz |
<old_time> |
aruba.time.old_time |
<oldtz> |
aruba.time.old_tz |
| Docs Field | Schema Mapping |
|---|---|
<process_name> |
process.name |
<reason> |
event.reason |
<reboot_num> |
aruba.tpm.reboot_num |
| Docs Field | Schema Mapping |
|---|---|
<instance_name> |
aruba.instance.id |
<monitor_name> |
aruba.traffic.monitor_name |
| Docs Field | Schema Mapping |
|---|---|
<adapter_desc> |
aruba.xcvr.desc |
<count> |
aruba.count |
<disabled_reason> |
event.reason |
<interface> |
aruba.interface.id |
<list> |
aruba.xcvr.list |
<path> |
aruba.xcvr.path |
<reason> |
event.reason |
<status> |
aruba.status |
<xcvr_desc> |
aruba.xcvr.desc |
| Docs Field | Schema Mapping |
|---|---|
<intf> |
aruba.interface.id |
<intvl_a> |
aruba.udld.intvl_a |
<intvl_b> |
aruba.udld.intvl_b |
| Docs Field | Schema Mapping |
|---|
| Docs Field | Schema Mapping |
|---|---|
<from_state> |
aruba.ufd.from_state |
<id> |
aruba.instance.id |
<to_state> |
aruba.state |
| Docs Field | Schema Mapping |
|---|---|
<added_user> |
aruba.user.added_user |
<deleted_user> |
aruba.user.deleted_user |
<user> |
user.name |
<user_role> |
aruba.user.role |
<username> |
user.name |
| Docs Field | Schema Mapping |
|---|---|
<client_mac> |
client.mac |
<dst_ip> |
destination.ip |
<ecmp_id> |
aruba.tunnel.ecmp_id |
<gre_key> |
aruba.tunnel.gre_key |
<mac_addr> |
client.mac |
<nfd_id> |
aruba.tunnel.nfd_id |
<port> |
aruba.port |
<reason> |
event.reason |
<sac_ip> |
server.ip |
<src_ip> |
source.ip |
<state> |
aruba.state |
<tunnel_id> |
aruba.instance.id |
<uac_ip> |
client.ip |
<version> |
service.version |
<vlan_id> |
network.vlan.id |
<vrf> |
aruba.vrf.id |
<zone> |
aruba.tunnel.zone |
| Docs Field | Schema Mapping |
|---|---|
<bank_name> |
aruba.vsx.bank_name |
<ifname> |
aruba.interface.name |
<local_device_type> |
aruba.vsx.local_device_type |
<local_sw_ver> |
aruba.vsx.local_sw_ver |
<local_vsx_role> |
aruba.vsx.local_vsx_role |
<peer_device_type> |
aruba.vsx.peer_device_type |
<peer_sw_ver> |
aruba.vsx.peer_sw_ver |
<peer_vsx_role> |
aruba.vsx.peer_vsx_role |
<port> |
aruba.port |
<prev_state> |
aruba.vsx.prev_state |
<primary_version> |
aruba.vsx.primary_version |
<reason> |
event.reason |
<secondary_version> |
aruba.vsx.secondary_version |
<state> |
aruba.state |
<sub_state> |
aruba.vsx.sub_state |
<value> |
server.ip |
<vsx_id> |
aruba.instance.id |
<vsx_role> |
aruba.role |
| Docs Field | Schema Mapping |
|---|---|
<id> |
aruba.instance.id |
<if_name> |
aruba.interface.name |
<link> |
aruba.vsf.link |
<link_id> |
aruba.vsf.link |
<lowest_speed> |
aruba.vsf.lowest_speed |
<mac_add> |
aruba.vsf.mac_addr1 / aruba.vsf.mac_addr2 |
<mac_addr> |
aruba.vsf.mac_addr1 / aruba.vsf.mac_addr2 |
<mac_addr1> |
aruba.vsf.mac_addr1 |
<mac_addr2> |
aruba.vsf.mac_addr2 |
<mac_address> |
aruba.vsf.mac_addr1 / aruba.vsf.mac_addr2 |
<mbr_id> |
aruba.vsf.mbr_id |
<member_id> |
aruba.vsf.member_id |
<new_standby_id> |
aruba.vsf.new_standby_id |
<old_standby_id> |
aruba.vsf.old_standby_id |
<operation> |
aruba.vsf.operation |
<port> |
aruba.port |
<port_id> |
aruba.port |
<port_id> |
aruba.vsf.port2 |
<product_id> |
aruba.vsf.product_id |
<prod_type> |
aruba.vsf.product_type |
<product_type> |
aruba.vsf.product_type |
<reason> |
event.reason |
<status> |
aruba.status |
<topo_type> |
aruba.vsf.topo_type |
<type> |
aruba.vsf.product_type |
| Docs Field | Schema Mapping |
|---|---|
<from> |
aruba.vlan.from |
<intf_name> |
aruba.interface.name |
<local_node> |
aruba.vlan.local_node |
<mac> |
server.mac |
<orig_vlan> |
aruba.vlan.orig_vlan |
<port> |
aruba.port |
<port_name> |
aruba.port |
<prim_admin> |
aruba.vlan.prim_admin |
<prim_vid> |
aruba.vlan.prim_vid |
<reason> |
event.reason |
<rst> |
event.reason |
<remote_node> |
aruba.vlan.remote_node |
<sec_admin> |
aruba.vlan.sec_admin |
<sec_type> |
aruba.vlan.sec_type |
<sec_vid> |
aruba.vlan.sec_vid |
<to> |
aruba.vlan.to |
<trans_vlan> |
aruba.vlan.trans_vlan |
<vlan> |
network.vlan.id |
<vid> |
network.vlan.id |
| Docs Field | Schema Mapping |
|---|---|
<error> |
event.reason |
<interface> |
aruba.interface.id |
<vlan> |
network.vlan.id |
| Docs Field | Schema Mapping |
|---|---|
<vrf_name> |
aruba.vrf.name |
| Docs Field | Schema Mapping |
|---|---|
<vrf_entity> |
aruba.vrf.name |
| Docs Field | Schema Mapping |
|---|---|
<address> |
service.address |
<interface> |
aruba.interface.id |
<inet_type> |
aruba.vrrp.inet_type |
<new_state> |
aruba.state |
<old_state> |
aruba.vrrp.old_state |
<track> |
aruba.vrrp.track |
<type> |
aruba.vrrp.type |
<value> |
service.version |
<value> |
aruba.vrrp.delay |
<value> |
aruba.vrrp.interval |
<value> |
aruba.priority |
<value> |
aruba.vrrp.mode |
<vrid> |
aruba.instance.id |
| Docs Field | Schema Mapping |
|---|---|
<id> |
aruba.instance.id |
| Docs Field | Schema Mapping |
|---|---|
<ecmp_id> |
aruba.vxlan.ecmp_id |
<tunnel_id> |
aruba.vxlan.tunnel_id |
<vlan> |
network.vlan.id |
<vni_id> |
aruba.vxlan.vni_id |
| Docs Field | Schema Mapping |
|---|---|
<action> |
event.action |
<port> |
aruba.port |
<port_name> |
aruba.port |
<remote_ip> |
client.ip |
<state> |
aruba.state |
<vlan_id> |
network.vlan.id |
<vni_id> |
aruba.vxlan.vni_id |
<vtep> |
aruba.vxlan.vtep |
<vtep_peer> |
aruba.vxlan.vtep_peer |
| Docs Field | Schema Mapping |
|---|---|
<alt_aruba_central_loc> |
aruba.ztp.alt_aruba_central_loc |
<central_location> |
aruba.ztp.central_location |
<config_file> |
file.name |
<filename> |
file.name |
<http_proxy_location> |
aruba.ztp.http_proxy_location |
<image_file> |
file.name |
<reason> |
event.reason |
<tftp_ip> |
server.ip |
The log dataset collects the HPE Aruba CX logs.
Exported fields
| Field | Description | Type |
|---|---|---|
| @timestamp | Event timestamp. | date |
| agent.name | Custom name of the agent. This is a name that can be given to an agent. This can be helpful if for example two Filebeat instances are running on the same host but a human readable separation is needed on which Filebeat instance data is coming from. | keyword |
| aruba.aaa.config_event | keyword | |
| aruba.aaa.config_type | keyword | |
| aruba.aaa.radius_action | keyword | |
| aruba.aaa.radius_event | keyword | |
| aruba.aaa.radius_type | keyword | |
| aruba.aaa.tacacs_action | keyword | |
| aruba.aaa.tacacs_event | keyword | |
| aruba.aaa.tacacs_type | keyword | |
| aruba.acc_abp.client | keyword | |
| aruba.acc_abp.operation | keyword | |
| aruba.acc_abp.pac_abp_name | keyword | |
| aruba.acc_abp.result | keyword | |
| aruba.acl.ace_string | TBD for all description fields - need to be filled in | keyword |
| aruba.acl.application | keyword | |
| aruba.acl.direction | keyword | |
| aruba.acl.hit_delta | long | |
| aruba.acl.name | keyword | |
| aruba.acl.type | keyword | |
| aruba.alarm.log_and_trap | keyword | |
| aruba.alarm.name | keyword | |
| aruba.alarm.relay | keyword | |
| aruba.alarm.trigger | keyword | |
| aruba.alarm.type | keyword | |
| aruba.arc.log | keyword | |
| aruba.asic.prefix_list | keyword | |
| aruba.asic.route_prefix | keyword | |
| aruba.bfd.applied_interval | long | |
| aruba.bfd.direction | keyword | |
| aruba.bfd.from | keyword | |
| aruba.bfd.invalid_ip | ip | |
| aruba.bfd.ip_version | keyword | |
| aruba.bfd.local_diag | keyword | |
| aruba.bfd.local_state | keyword | |
| aruba.bfd.op_mode | keyword | |
| aruba.bfd.remote_diag | keyword | |
| aruba.bfd.remote_state | keyword | |
| aruba.bfd.requested_interval | long | |
| aruba.bgp.as_number | long | |
| aruba.bgp.error_subcode | keyword | |
| aruba.bgp.id | keyword | |
| aruba.bgp.peer_grp | keyword | |
| aruba.bgp.pg_name | keyword | |
| aruba.bgp.vtep_ip | ip | |
| aruba.cm.cert_name | keyword | |
| aruba.cm.days | long | |
| aruba.cm.est_name | keyword | |
| aruba.cm.profile_name | keyword | |
| aruba.component.category | keyword | |
| aruba.component.name | keyword | |
| aruba.config.from | keyword | |
| aruba.config.name | keyword | |
| aruba.config.to | keyword | |
| aruba.config.type | keyword | |
| aruba.config.value | keyword | |
| aruba.container.params | keyword | |
| aruba.copp.class | Control Plane Policing (CoPP) class | keyword |
| aruba.count | long | |
| aruba.cpu_rx.filter_description | keyword | |
| aruba.dhcp.bindings_imported | keyword | |
| aruba.dhcp.config | keyword | |
| aruba.dhcp.gateway_ip | ip | |
| aruba.dhcp.ipv6_address | keyword | |
| aruba.dhcp.lease | keyword | |
| aruba.dhcp.lease_ip_address | ip | |
| aruba.dhcp.message_type | keyword | |
| aruba.dhcp.nameserver_ip | ip | |
| aruba.dhcp.new_port | keyword | |
| aruba.dhcp.server_ip_address | ip | |
| aruba.dhcp.source_mac | keyword | |
| aruba.dhcp.volume_name | keyword | |
| aruba.distributed.active_coordinates | keyword | |
| aruba.distributed.configured_coordinates | keyword | |
| aruba.dns.type | keyword | |
| aruba.dns.vrf_name | keyword | |
| aruba.dot1x.policy | keyword | |
| aruba.dpse.linecard_name | keyword | |
| aruba.dpse.operation_name | keyword | |
| aruba.dpse.plugin_name | keyword | |
| aruba.ecmp.egressid | keyword | |
| aruba.ecmp.err | keyword | |
| aruba.ecmp.route | keyword | |
| aruba.erps.ring_id | keyword | |
| aruba.error.count | long | |
| aruba.error.description | keyword | |
| aruba.event_type | keyword | |
| aruba.evpn.esi | keyword | |
| aruba.evpn.eth_tag | keyword | |
| aruba.evpn.rd | keyword | |
| aruba.evpn.rt | keyword | |
| aruba.evpn.rtt | keyword | |
| aruba.evpn.vni | keyword | |
| aruba.evpn.vtep_ip | ip | |
| aruba.fan.air_flow_direction | keyword | |
| aruba.fan.compare_mode | keyword | |
| aruba.fan.count | long | |
| aruba.fan.en_dis | keyword | |
| aruba.fan.fan_index | long | |
| aruba.fan.fmod_num | keyword | |
| aruba.fan.ft_air_curr | keyword | |
| aruba.fan.ft_air_req | keyword | |
| aruba.fan.ft_dir | keyword | |
| aruba.fan.ft_name | keyword | |
| aruba.fan.function | keyword | |
| aruba.fan.index | long | |
| aruba.fan.minimum | long | |
| aruba.fan.module_idx | long | |
| aruba.fan.name | keyword | |
| aruba.fan.new_status | keyword | |
| aruba.fan.old_status | keyword | |
| aruba.fan.speedval | keyword | |
| aruba.fan.tray_idx | long | |
| aruba.fan.value | keyword | |
| aruba.fan.zone_idx | long | |
| aruba.fault.da_diff_count | long | |
| aruba.fault.sa_diff_count | long | |
| aruba.fault.type | keyword | |
| aruba.feature_pack.device_parameter | keyword | |
| aruba.feature_pack.device_serial | keyword | |
| aruba.feature_pack.expiry_date | keyword | |
| aruba.feature_pack.feature_name | keyword | |
| aruba.feature_pack.mode | keyword | |
| aruba.feature_pack.name | keyword | |
| aruba.feature_pack.parameter_type | keyword | |
| aruba.feature_pack.parameter_type_mismatch | keyword | |
| aruba.feature_pack.subscription_parameter | keyword | |
| aruba.feature_pack.type | keyword | |
| aruba.firmware.after | keyword | |
| aruba.firmware.before | keyword | |
| aruba.firmware.dnld_type | keyword | |
| aruba.firmware.hotpatch_name | keyword | |
| aruba.firmware.image_profile | keyword | |
| aruba.fqtss.classA_ded | keyword | |
| aruba.fqtss.classA_max | keyword | |
| aruba.fqtss.classB_ded | keyword | |
| aruba.fqtss.classB_max | keyword | |
| aruba.fqtss.dedicate_mem_status | keyword | |
| aruba.fqtss.per_port_consolidate_status | keyword | |
| aruba.fqtss.per_port_per_stream_consolidate_status | keyword | |
| aruba.fqtss.per_port_status | keyword | |
| aruba.fqtss.per_stream_consolidate_status | keyword | |
| aruba.fqtss.per_stream_status | keyword | |
| aruba.fqtss.request_type | keyword | |
| aruba.fqtss.stream_hw_status | keyword | |
| aruba.fqtss.stream_meter_id | keyword | |
| aruba.hardware.addr | keyword | |
| aruba.hardware.bus | keyword | |
| aruba.hardware.cap | keyword | |
| aruba.hardware.cecount | long | |
| aruba.hardware.channel | keyword | |
| aruba.hardware.cpus | long | |
| aruba.hardware.device | keyword | |
| aruba.hardware.function | keyword | |
| aruba.hardware.impact_statement | keyword | |
| aruba.hardware.level | keyword | |
| aruba.hardware.location | keyword | |
| aruba.hardware.mcgstatus | keyword | |
| aruba.hardware.misc | keyword | |
| aruba.hardware.offlined | long | |
| aruba.hardware.origin | keyword | |
| aruba.hardware.page | keyword | |
| aruba.hardware.seg | keyword | |
| aruba.hardware.socket | keyword | |
| aruba.hardware.test_name | keyword | |
| aruba.hardware.type | keyword | |
| aruba.hardware.vni | keyword | |
| aruba.hotpatch.ss | keyword | |
| aruba.injected_view.name | keyword | |
| aruba.insight.arp_end_ts | keyword | |
| aruba.insight.auth_latency | keyword | |
| aruba.insight.auth_type | keyword | |
| aruba.insight.dhcp_client | keyword | |
| aruba.insight.dhcp_latency | keyword | |
| aruba.insight.dhcp_server | keyword | |
| aruba.insight.dns_end_ts | keyword | |
| aruba.insight.dns_latency | keyword | |
| aruba.insight.dns_server | keyword | |
| aruba.insight.dot1x_auth_failure_reason | keyword | |
| aruba.insight.failed_vlans | keyword | |
| aruba.insight.failure_phase_id | keyword | |
| aruba.insight.l2_end_ts | keyword | |
| aruba.insight.l2_failure_reason | keyword | |
| aruba.insight.l2_ob_state | keyword | |
| aruba.insight.l3_end_ts | keyword | |
| aruba.insight.l3_failure_reason | keyword | |
| aruba.insight.l3_ob_state | keyword | |
| aruba.insight.mac_auth_failure_reason | keyword | |
| aruba.insight.ob_start_ts | keyword | |
| aruba.insight.radius_server | keyword | |
| aruba.insight.role_type | keyword | |
| aruba.insight.successfulvlan | keyword | |
| aruba.instance.id | keyword | |
| aruba.interface.id | keyword | |
| aruba.interface.name | keyword | |
| aruba.interface.port_speed | long | |
| aruba.interface.prev_id | keyword | |
| aruba.ip_ra.route | keyword | |
| aruba.ip_sla.name | keyword | |
| aruba.issu.active_bank | keyword | |
| aruba.issu.condition | keyword | |
| aruba.issu.feature | keyword | |
| aruba.issu.location | keyword | |
| aruba.issu.new_software_version | keyword | |
| aruba.issu.operation | keyword | |
| aruba.issu.previous_software_version | keyword | |
| aruba.issu.wait_time | long | |
| aruba.l3.encaps_allocated | keyword | |
| aruba.l3.encaps_free | keyword | |
| aruba.l3.nexthop | keyword | |
| aruba.l3.object | keyword | |
| aruba.l3.percent | long | |
| aruba.l3.resource | keyword | |
| aruba.l3.vtep | keyword | |
| aruba.lacp.actor_state | keyword | |
| aruba.lacp.fallback | keyword | |
| aruba.lacp.fallback_mode | keyword | |
| aruba.lacp.fsm_state | keyword | |
| aruba.lacp.lag_number | long | |
| aruba.lacp.lag_speed | long | |
| aruba.lacp.mode | keyword | |
| aruba.lacp.partner_state | keyword | |
| aruba.lacp.partner_sys_id | keyword | |
| aruba.lacp.port_speed | long | |
| aruba.lacp.rate | keyword | |
| aruba.lacp.system_id | keyword | |
| aruba.lacp.system_priority | keyword | |
| aruba.lag.mode | keyword | |
| aruba.lag.psc | keyword | |
| aruba.launchd.daemon | keyword | |
| aruba.len | long | |
| aruba.limit.read_value | long | |
| aruba.limit.threshold | keyword | |
| aruba.lldp.ninterface | keyword | |
| aruba.lldp.npvid | long | |
| aruba.lldp.pvid | long | |
| aruba.lldp.reinit_delay | long | |
| aruba.lldp.tx_delay | long | |
| aruba.lldp.tx_hold | long | |
| aruba.lldp.tx_timer | long | |
| aruba.loop.rx_port | keyword | |
| aruba.loop.tx_port | keyword | |
| aruba.mac.ckn | keyword | |
| aruba.mac.feature | keyword | |
| aruba.mac.latest_an | keyword | |
| aruba.mac.latest_kn | keyword | |
| aruba.mac.new_mode | keyword | |
| aruba.mac.old_an | keyword | |
| aruba.mac.old_kn | keyword | |
| aruba.mac.old_mode | keyword | |
| aruba.mac.sci | keyword | |
| aruba.management.config_param | keyword | |
| aruba.mgmd.l3_port | keyword | |
| aruba.mgmd.mgmd_type | keyword | |
| aruba.mgmd.pkt_type | keyword | |
| aruba.mgmd.port1 | keyword | |
| aruba.mgmd.protocol | keyword | |
| aruba.mgmd.ring_id | keyword | |
| aruba.mgmd.type | keyword | |
| aruba.mgmt.config_crit | object | |
| aruba.mgmt.config_err | object | |
| aruba.mgmt.config_param | object | |
| aruba.module.name | keyword | |
| aruba.module.new_part | keyword | |
| aruba.module.old_part | keyword | |
| aruba.module.type | keyword | |
| aruba.mpls.local_ldp_id | keyword | |
| aruba.mpls.peer_ldp_id | keyword | |
| aruba.msdp.grp_ip | ip | |
| aruba.msdp.rp_ip | ip | |
| aruba.msdp.tcp_entity | keyword | |
| aruba.msrp.decl_type | keyword | |
| aruba.mstp.config_parameter | keyword | |
| aruba.mstp.config_value | keyword | |
| aruba.mstp.new_mode | keyword | |
| aruba.mstp.old_mac | keyword | |
| aruba.mstp.old_mode | keyword | |
| aruba.mstp.old_port | keyword | |
| aruba.mstp.old_priority | keyword | |
| aruba.mstp.pkt_type | keyword | |
| aruba.mstp.priority_mac | keyword | |
| aruba.mstp.proto | keyword | |
| aruba.mstp.reconfig_parameter | keyword | |
| aruba.mtu | keyword | |
| aruba.multicast.encap_type | keyword | |
| aruba.multicast.flood_group_ip | ip | |
| aruba.multicast.flood_group_range | keyword | |
| aruba.multicast.ip_assign_method | keyword | |
| aruba.multicast.isl_rule | keyword | |
| aruba.multicast.mgmd_type | keyword | |
| aruba.multicast.override_group_ip | keyword | |
| aruba.multicast.rep_mode | keyword | |
| aruba.multicast.ulay_l2_port | keyword | |
| aruba.multicast.ulay_l3_port | keyword | |
| aruba.multicast.vni_id | keyword | |
| aruba.nae.action_type | keyword | |
| aruba.nae.condition | keyword | |
| aruba.nae.description | keyword | |
| aruba.nae.monitor_name | keyword | |
| aruba.nae.name | keyword | |
| aruba.nd.type | keyword | |
| aruba.ndm.new_mac | keyword | |
| aruba.ndm.old_mac | keyword | |
| aruba.ndm.old_role | keyword | |
| aruba.ntp.event | keyword | |
| aruba.ntp.old | keyword | |
| aruba.ntp.server_info | keyword | |
| aruba.ntp.trusted_keys | keyword | |
| aruba.ntp.untrusted_keys | keyword | |
| aruba.ospf.area | keyword | |
| aruba.ospf.event | keyword | |
| aruba.ospf.external | keyword | |
| aruba.ospf.fp_id | keyword | |
| aruba.ospf.input | keyword | |
| aruba.ospf.inter | keyword | |
| aruba.ospf.intra | keyword | |
| aruba.ospf.link_local | ip | |
| aruba.ospf.nexthops | keyword | |
| aruba.ospf.old_router_id | keyword | |
| aruba.ospf.old_state | keyword | |
| aruba.ospf.router_id | keyword | |
| aruba.ospf.stats_id | keyword | |
| aruba.pac_gbp.client | keyword | |
| aruba.pac_gbp.line_card | keyword | |
| aruba.pac_gbp.name | keyword | |
| aruba.pac_gbp.operation | keyword | |
| aruba.pac_gbp.result | keyword | |
| aruba.packet_capture.session_name | keyword | |
| aruba.packet_capture.value | keyword | |
| aruba.pim.callerid | keyword | |
| aruba.pim.capacity_type | keyword | |
| aruba.pim.dip0 | keyword | |
| aruba.pim.dip1 | keyword | |
| aruba.pim.dip2 | keyword | |
| aruba.pim.dip3 | keyword | |
| aruba.pim.ebsr_ip | ip | |
| aruba.pim.error_value | keyword | |
| aruba.pim.event | keyword | |
| aruba.pim.fd | keyword | |
| aruba.pim.flowtype | keyword | |
| aruba.pim.ip_version | keyword | |
| aruba.pim.mode | keyword | |
| aruba.pim.pkt_type | keyword | |
| aruba.pim.qsize | long | |
| aruba.pim.sip0 | keyword | |
| aruba.pim.sip1 | keyword | |
| aruba.pim.sip2 | keyword | |
| aruba.pim.sip3 | keyword | |
| aruba.pim.totalvid | long | |
| aruba.pim.type | keyword | |
| aruba.poe.assigned_class | keyword | |
| aruba.poe.assigned_class_a | keyword | |
| aruba.poe.assigned_class_b | keyword | |
| aruba.poe.available | keyword | |
| aruba.poe.cntrl_name | keyword | |
| aruba.poe.duration | keyword | |
| aruba.poe.fault_type | keyword | |
| aruba.poe.pair | keyword | |
| aruba.poe.paira_class | keyword | |
| aruba.poe.pairb_class | keyword | |
| aruba.poe.pd_class | keyword | |
| aruba.poe.pd_type | keyword | |
| aruba.poe.req_class | keyword | |
| aruba.poe.req_class_a | keyword | |
| aruba.poe.req_class_b | keyword | |
| aruba.poe.subsys_name | keyword | |
| aruba.policy.application | keyword | |
| aruba.policy.name | keyword | |
| aruba.port | keyword | |
| aruba.port_access.auth_method | keyword | |
| aruba.port_access.feature | keyword | |
| aruba.port_access.mode | keyword | |
| aruba.port_access.monitor_name | keyword | |
| aruba.port_access.name | keyword | |
| aruba.port_access.num_cached_clients | long | |
| aruba.port_access.old_limit | keyword | |
| aruba.port_access.old_mode | keyword | |
| aruba.port_access.old_name | keyword | |
| aruba.port_access.request_id | keyword | |
| aruba.port_access.request_pkt | keyword | |
| aruba.port_access.server_list | keyword | |
| aruba.power.alert | keyword | |
| aruba.power.available | keyword | |
| aruba.power.fanidx | long | |
| aruba.power.fault | keyword | |
| aruba.power.name | keyword | |
| aruba.power.redund | keyword | |
| aruba.power.sensorid | keyword | |
| aruba.power.support | keyword | |
| aruba.power.type | keyword | |
| aruba.power.value | keyword | |
| aruba.prefix | keyword | |
| aruba.priority | keyword | |
| aruba.ptp.clock_step | keyword | |
| aruba.ptp.curr_offset | keyword | |
| aruba.ptp.delay_mechanism | keyword | |
| aruba.ptp.grandsource | keyword | |
| aruba.ptp.high_limit | keyword | |
| aruba.ptp.lag_name | keyword | |
| aruba.ptp.low_limit | keyword | |
| aruba.ptp.new | keyword | |
| aruba.ptp.old | keyword | |
| aruba.ptp.parent | keyword | |
| aruba.ptp.priority1 | keyword | |
| aruba.ptp.priority2 | keyword | |
| aruba.ptp.profile | keyword | |
| aruba.ptp.quality | keyword | |
| aruba.ptp.transport | keyword | |
| aruba.ptp.type | keyword | |
| aruba.ptp.value | keyword | |
| aruba.qos.new_slot | keyword | |
| aruba.qos.queue | keyword | |
| aruba.redundant.mgmt_module | keyword | |
| aruba.rest.activate_address | keyword | |
| aruba.rest.added_user | keyword | |
| aruba.rest.autztype | keyword | |
| aruba.rest.central_location | keyword | |
| aruba.rest.central_source | keyword | |
| aruba.rest.command | keyword | |
| aruba.rest.config_from_name | keyword | |
| aruba.rest.config_name | keyword | |
| aruba.rest.config_to_name | keyword | |
| aruba.rest.deleted_user | keyword | |
| aruba.rest.dns | keyword | |
| aruba.rest.dns_nameserver | keyword | |
| aruba.rest.identity | keyword | |
| aruba.rest.match | keyword | |
| aruba.rest.mode | keyword | |
| aruba.rest.name | keyword | |
| aruba.rest.operation | keyword | |
| aruba.rest.resource | keyword | |
| aruba.rest.subscriber | keyword | |
| aruba.rest.subscription | keyword | |
| aruba.rest.type | keyword | |
| aruba.role | keyword | |
| aruba.rpvst.new_mode | keyword | |
| aruba.rpvst.npvid | keyword | |
| aruba.rpvst.old_mac | keyword | |
| aruba.rpvst.old_mode | keyword | |
| aruba.rpvst.old_port | keyword | |
| aruba.rpvst.old_priority | keyword | |
| aruba.rpvst.pkt_type | keyword | |
| aruba.rpvst.proto | keyword | |
| aruba.rpvst.pvid | keyword | |
| aruba.scheduler.datetime | keyword | |
| aruba.scheduler.details | keyword | |
| aruba.scheduler.job_name | keyword | |
| aruba.scheduler.name | keyword | |
| aruba.self_test.stack | keyword | |
| aruba.sequence | keyword | |
| aruba.server.mode | keyword | |
| aruba.server.sessions | long | |
| aruba.session.id | keyword | |
| aruba.session.name | keyword | |
| aruba.sflow.bridge | keyword | |
| aruba.sflow.chain | keyword | |
| aruba.sflow.dgramsize | long | |
| aruba.sflow.intvl | keyword | |
| aruba.sflow.mode | keyword | |
| aruba.sflow.new_rate | keyword | |
| aruba.sflow.old_rate | keyword | |
| aruba.sflow.operation | keyword | |
| aruba.slot | long | |
| aruba.snmp.truth_value | keyword | |
| aruba.ssh.key_name | keyword | |
| aruba.ssh.new_ip | keyword | |
| aruba.state | keyword | |
| aruba.status | keyword | |
| aruba.storage.name | keyword | |
| aruba.storage.usage | long | |
| aruba.subsystem | keyword | |
| aruba.supportability.alarm_index | keyword | |
| aruba.supportability.daemons | keyword | |
| aruba.supportability.log_type | keyword | |
| aruba.supportability.module | keyword | |
| aruba.supportability.oid | keyword | |
| aruba.sys.module | keyword | |
| aruba.sys.name | keyword | |
| aruba.sysmon.mem_usage | long | |
| aruba.sysmon.module_name | keyword | |
| aruba.sysmon.module_num | long | |
| aruba.sysmon.partition_name | keyword | |
| aruba.sysmon.poll | keyword | |
| aruba.sysmon.unit | keyword | |
| aruba.sysmon.unit_count | long | |
| aruba.sysmon.utilization | long | |
| aruba.system.devicespec | keyword | |
| aruba.system.line | long | |
| aruba.system.modspec | keyword | |
| aruba.system.numdevs | long | |
| aruba.system.pass | keyword | |
| aruba.system.time | long | |
| aruba.tcam.table_name | keyword | |
| aruba.temp.celsius | long | |
| aruba.temp.limit_type | keyword | |
| aruba.temp.module | keyword | |
| aruba.temp.name | keyword | |
| aruba.temp.new | keyword | |
| aruba.temp.old | keyword | |
| aruba.temp.t_high | long | |
| aruba.temp.t_low | long | |
| aruba.temp.type | keyword | |
| aruba.throttle_count | long | |
| aruba.time.new_time | keyword | |
| aruba.time.new_tz | keyword | |
| aruba.time.old_time | keyword | |
| aruba.time.old_tz | keyword | |
| aruba.time.seconds | long | |
| aruba.timeout | long | |
| aruba.tpm.reboot_num | keyword | |
| aruba.traffic.monitor_name | keyword | |
| aruba.tunnel.ecmp_id | keyword | |
| aruba.tunnel.gre_key | keyword | |
| aruba.tunnel.name | keyword | |
| aruba.tunnel.nfd_id | keyword | |
| aruba.tunnel.ttl | keyword | |
| aruba.tunnel.type | keyword | |
| aruba.tunnel.zone | keyword | |
| aruba.udld.intvl_a | keyword | |
| aruba.udld.intvl_b | keyword | |
| aruba.ufd.from_state | ||
| aruba.unit | keyword | |
| aruba.user.added_user | keyword | |
| aruba.user.deleted_user | keyword | |
| aruba.user.role | keyword | |
| aruba.vlan.from | keyword | |
| aruba.vlan.local_node | keyword | |
| aruba.vlan.orig_vlan | keyword | |
| aruba.vlan.prim_admin | keyword | |
| aruba.vlan.prim_vid | keyword | |
| aruba.vlan.remote_node | keyword | |
| aruba.vlan.sec_admin | keyword | |
| aruba.vlan.sec_type | keyword | |
| aruba.vlan.sec_vid | keyword | |
| aruba.vlan.to | keyword | |
| aruba.vlan.trans_vlan | keyword | |
| aruba.vrf.id | keyword | |
| aruba.vrf.name | keyword | |
| aruba.vrrp.delay | long | |
| aruba.vrrp.inet_type | keyword | |
| aruba.vrrp.interval | long | |
| aruba.vrrp.mode | keyword | |
| aruba.vrrp.old_state | keyword | |
| aruba.vrrp.track | keyword | |
| aruba.vrrp.type | ||
| aruba.vsf.link | keyword | |
| aruba.vsf.lowest_speed | keyword | |
| aruba.vsf.mac_addr1 | keyword | |
| aruba.vsf.mac_addr2 | keyword | |
| aruba.vsf.mbr_id | keyword | |
| aruba.vsf.member_id | keyword | |
| aruba.vsf.new_standby_id | keyword | |
| aruba.vsf.old_standby_id | keyword | |
| aruba.vsf.operation | keyword | |
| aruba.vsf.port2 | keyword | |
| aruba.vsf.product_id | keyword | |
| aruba.vsf.product_type | keyword | |
| aruba.vsf.topo_type | keyword | |
| aruba.vsx.bank_name | keyword | |
| aruba.vsx.local_device_type | keyword | |
| aruba.vsx.local_sw_ver | keyword | |
| aruba.vsx.local_vsx_role | keyword | |
| aruba.vsx.peer_device_type | keyword | |
| aruba.vsx.peer_sw_ver | keyword | |
| aruba.vsx.peer_vsx_role | keyword | |
| aruba.vsx.prev_state | keyword | |
| aruba.vsx.primary_version | keyword | |
| aruba.vsx.secondary_version | keyword | |
| aruba.vsx.sub_state | keyword | |
| aruba.vxlan.ecmp_id | keyword | |
| aruba.vxlan.tunnel_id | keyword | |
| aruba.vxlan.vni_id | keyword | |
| aruba.vxlan.vtep | keyword | |
| aruba.vxlan.vtep_peer | keyword | |
| aruba.xcvr.desc | keyword | |
| aruba.xcvr.list | keyword | |
| aruba.xcvr.path | keyword | |
| aruba.ztp.alt_aruba_central_loc | keyword | |
| aruba.ztp.central_location | keyword | |
| aruba.ztp.http_proxy_location | keyword | |
| client.as.number | Unique number allocated to the autonomous system. The autonomous system number (ASN) uniquely identifies each network on the Internet. | long |
| client.ip | IP address of the client (IPv4 or IPv6). | ip |
| client.mac | MAC address of the client. The notation format from RFC 7042 is suggested: Each octet (that is, 8-bit byte) is represented by two [uppercase] hexadecimal digits giving the value of the octet as an unsigned integer. Successive octets are separated by a hyphen. | keyword |
| container.name | Container name. | keyword |
| data_stream.dataset | Data stream dataset. | constant_keyword |
| data_stream.namespace | Data stream namespace. | constant_keyword |
| data_stream.type | Data stream type. | constant_keyword |
| destination.address | Some event destination addresses are defined ambiguously. The event will sometimes list an IP, a domain or a unix socket. You should always store the raw address in the .address field. Then it should be duplicated to .ip or .domain, depending on which one it is. |
keyword |
| destination.as.number | Unique number allocated to the autonomous system. The autonomous system number (ASN) uniquely identifies each network on the Internet. | long |
| destination.ip | IP address of the destination (IPv4 or IPv6). | ip |
| destination.mac | MAC address of the destination. The notation format from RFC 7042 is suggested: Each octet (that is, 8-bit byte) is represented by two [uppercase] hexadecimal digits giving the value of the octet as an unsigned integer. Successive octets are separated by a hyphen. | keyword |
| ecs.version | ECS version this event conforms to. ecs.version is a required field and must exist in all events. When querying across multiple indices -- which may conform to slightly different ECS versions -- this field lets integrations adjust to the schema version of the events. |
keyword |
| error.code | Error code describing the error. | keyword |
| error.message | Error message. | match_only_text |
| error.type | The type of the error, for example the class name of the exception. | keyword |
| event.action | The action captured by the event. This describes the information in the event. It is more specific than event.category. Examples are group-add, process-started, file-created. The value is normally defined by the implementer. |
keyword |
| event.category | This is one of four ECS Categorization Fields, and indicates the second level in the ECS category hierarchy. event.category represents the "big buckets" of ECS categories. For example, filtering on event.category:process yields all events relating to process activity. This field is closely related to event.type, which is used as a subcategory. This field is an array. This will allow proper categorization of some events that fall in multiple categories. |
keyword |
| event.code | Identification code for this event, if one exists. Some event sources use event codes to identify messages unambiguously, regardless of message language or wording adjustments over time. An example of this is the Windows Event ID. | keyword |
| event.end | event.end contains the date when the event ended or when the activity was last observed. |
date |
| event.id | Unique ID to describe the event. | keyword |
| event.kind | This is one of four ECS Categorization Fields, and indicates the highest level in the ECS category hierarchy. event.kind gives high-level information about what type of information the event contains, without being specific to the contents of the event. For example, values of this field distinguish alert events from metric events. The value of this field can be used to inform how these kinds of events should be handled. They may warrant different retention, different access control, it may also help understand whether the data is coming in at a regular interval or not. |
keyword |
| event.reason | Reason why this event happened, according to the source. This describes the why of a particular action or outcome captured in the event. Where event.action captures the action from the event, event.reason describes why that action was taken. For example, a web proxy with an event.action which denied the request may also populate event.reason with the reason why (e.g. blocked site). |
keyword |
| event.sequence | Sequence number of the event. The sequence number is a value published by some event sources, to make the exact ordering of events unambiguous, regardless of the timestamp precision. | long |
| event.type | This is one of four ECS Categorization Fields, and indicates the third level in the ECS category hierarchy. event.type represents a categorization "sub-bucket" that, when used along with the event.category field values, enables filtering events down to a level appropriate for single visualization. This field is an array. This will allow proper categorization of some events that fall in multiple event types. |
keyword |
| file.name | Name of the file including the extension, without the directory. | keyword |
| file.path | Full path to the file, including the file name. It should include the drive letter, when appropriate. | keyword |
| file.path.text | Multi-field of file.path. |
match_only_text |
| file.type | File type (file, dir, or symlink). | keyword |
| host.boot.id | Linux boot uuid taken from /proc/sys/kernel/random/boot_id. Note the boot_id value from /proc may or may not be the same in containers as on the host. Some container runtimes will bind mount a new boot_id value onto the proc file in each container. | keyword |
| host.ip | Host ip addresses. | ip |
| host.mac | Host MAC addresses. The notation format from RFC 7042 is suggested: Each octet (that is, 8-bit byte) is represented by two [uppercase] hexadecimal digits giving the value of the octet as an unsigned integer. Successive octets are separated by a hyphen. | keyword |
| host.name | Name of the host. It can contain what hostname returns on Unix systems, the fully qualified domain name (FQDN), or a name specified by the user. The recommended value is the lowercase FQDN of the host. | keyword |
| host.os.version | Operating system version as a raw string. | keyword |
| input.type | Input type | keyword |
| log.file.device_id | Device Id of the log file this event came from. | keyword |
| log.file.inode | Inode of the log file this event came from. | keyword |
| log.file.path | Full path to the log file this event came from, including the file name. It should include the drive letter, when appropriate. If the event wasn't read from a log file, do not populate this field. | keyword |
| log.level | Original log level of the log event. If the source of the event provides a log level or textual severity, this is the one that goes in log.level. If your source doesn't specify one, you may put your event transport's severity here (e.g. Syslog severity). Some examples are warn, err, i, informational. |
keyword |
| log.offset | Offset of the entry in the log file. | long |
| log.origin.file.line | The line number of the file containing the source code which originated the log event. | long |
| log.origin.file.name | The name of the file containing the source code which originated the log event. Note that this field is not meant to capture the log file. The correct field to capture the log file is log.file.path. |
keyword |
| log.source.address | Source address from which the log event was read / sent from. | keyword |
| log.syslog.appname | The device or application that originated the Syslog message, if available. | keyword |
| log.syslog.procid | The process name or ID that originated the Syslog message, if available. | keyword |
| log.syslog.severity.name | The Syslog numeric severity of the log event, if available. If the event source publishing via Syslog provides a different severity value (e.g. firewall, IDS), your source's text severity should go to log.level. If the event source does not specify a distinct severity, you can optionally copy the Syslog severity to log.level. |
keyword |
| message | For log events the message field contains the log message, optimized for viewing in a log viewer. For structured logs without an original message field, other fields can be concatenated to form a human-readable summary of the event. If multiple messages exist, they can be combined into one message. | match_only_text |
| network.direction | Direction of the network traffic. When mapping events from a host-based monitoring context, populate this field from the host's point of view, using the values "ingress" or "egress". When mapping events from a network or perimeter-based monitoring context, populate this field from the point of view of the network perimeter, using the values "inbound", "outbound", "internal" or "external". Note that "internal" is not crossing perimeter boundaries, and is meant to describe communication between two hosts within the perimeter. Note also that "external" is meant to describe traffic between two hosts that are external to the perimeter. This could for example be useful for ISPs or VPN service providers. | keyword |
| network.vlan.id | VLAN ID as reported by the observer. | keyword |
| observer.egress.interface.name | Interface name as reported by the system. | keyword |
| observer.ingress.interface.id | Interface ID as reported by an observer (typically SNMP interface ID). | keyword |
| observer.ingress.interface.name | Interface name as reported by the system. | keyword |
| package.installed | Time when package was installed. | date |
| package.name | Package name | keyword |
| package.version | Package version | keyword |
| process.end | The time the process ended. | date |
| process.name | Process name. Sometimes called program name or similar. | keyword |
| process.name.text | Multi-field of process.name. |
match_only_text |
| process.pid | Process id. | long |
| server.address | Some event server addresses are defined ambiguously. The event will sometimes list an IP, a domain or a unix socket. You should always store the raw address in the .address field. Then it should be duplicated to .ip or .domain, depending on which one it is. |
keyword |
| server.ip | IP address of the server (IPv4 or IPv6). | ip |
| server.mac | MAC address of the server. The notation format from RFC 7042 is suggested: Each octet (that is, 8-bit byte) is represented by two [uppercase] hexadecimal digits giving the value of the octet as an unsigned integer. Successive octets are separated by a hyphen. | keyword |
| server.port | Port of the server. | long |
| server.user.name | Short name or login of the user. | keyword |
| server.user.name.text | Multi-field of server.user.name. |
match_only_text |
| service.target.version | Version of the service the data was collected from. This allows to look at a data set only for a specific version of a service. | keyword |
| service.version | Version of the service the data was collected from. This allows to look at a data set only for a specific version of a service. | keyword |
| source.address | Some event source addresses are defined ambiguously. The event will sometimes list an IP, a domain or a unix socket. You should always store the raw address in the .address field. Then it should be duplicated to .ip or .domain, depending on which one it is. |
keyword |
| source.ip | IP address of the source (IPv4 or IPv6). | ip |
| source.mac | MAC address of the source. The notation format from RFC 7042 is suggested: Each octet (that is, 8-bit byte) is represented by two [uppercase] hexadecimal digits giving the value of the octet as an unsigned integer. Successive octets are separated by a hyphen. | keyword |
| tags | List of keywords used to tag each event. | keyword |
| url.domain | Domain of the url, such as "www.elastic.co". In some cases a URL may refer to an IP and/or port directly, without a domain name. In this case, the IP address would go to the domain field. If the URL contains a literal IPv6 address enclosed by [ and ] (IETF RFC 2732), the [ and ] characters should also be captured in the domain field. |
keyword |
| url.full | If full URLs are important to your use case, they should be stored in url.full, whether this field is reconstructed or present in the event source. |
wildcard |
| url.full.text | Multi-field of url.full. |
match_only_text |
| url.port | Port of the request, such as 443. | long |
| url.scheme | Scheme of the request, such as "https". Note: The : is not part of the scheme. |
keyword |
| user.id | Unique identifier of the user. | keyword |
| user.name | Short name or login of the user. | keyword |
| user.name.text | Multi-field of user.name. |
match_only_text |
Changelog
| Version | Details | Kibana version(s) |
|---|---|---|
| 0.1.0 | Enhancement (View pull request) Official support for HPE Aruba CX |
— |
